Camera
Image Sensor:1/2.8″ Progressive Scan CMOS
Effective Pixels:1920(H)x1080(V)
Signal System:PAL/NTSC
Minimum Illumination:Color: 0.05 Lux @ (F1.6, AGC ON)
B/W: 0.01 Lux @ (F1.6, AGC ON)
0 Lux with IR
White Balance:Auto/Manual/ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp
AGC:Auto/Manual
BLC:ON/OFF
HLC:Support
WDR:Support
Shutter Time:1/1 to 1/30,000s
Day& Night:ICR
Digital Zoom:16×
Privacy Masking:8 privacy masks programmable
Auto Focus:Auto / Semi-automatic / Manual

Lens
Focal Length:4.7 to 94mm
Zoom Speed:Approx. 2.7s
Angle of View:61.4° to 2.9° (wide-tele)
Minimum Working Distance:10 to 1500mm (wide-tele)
Aperture Range:F1.6 to F3.5

Pan & Tilt
Pan Range:360°endless
Pan Speed:Configurable, from 0.1°/s to 300°/s
Preset Speed: 350°/s
Tilt Range:-5°~90° (Auto Flip )
Tilt Speed:Configurable, from 0.1°/s to 160°/s
Preset Speed: 200°/s
Proportional Zoom:Rotation speed can be adjusted automatically according to zoom multiples
Number of Preset:300
Patrol:8 patrols, up to 32 presets for each patrol
Pattern:4 pattern scans, record time over 10 minutes for each scan
Power loss recovery:    Support
Park Action:Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan
PTZ Position Display:ON/OFF
Freeze Frame:Support
