Camera
Image Sensor:1/3″ Progressive Scan CMOS
Effective Pixels:1280(H)x720(V)
Signal System:PAL/NTSC
Minimum Illumination:Color: 0.05Lux@( F1.4,AGC ON); B/W: 0.005Lux@( F1.4,AGC ON), 0 Lux with IR
White Balance:Auto / Manual / ATW / Indoor / Outdoor
AGC:Auto/Manual
BLC:ON/OFF
WDR:Support
Shutter Time1-1/10,000s
Day& Night:ICR
Privacy Masking:8 privacy masks programmable
Auto Focus:Auto / Semi-automatic / Manual

Lens
Focal Length:4-92.0mm, 23x
Zoom Speed:Approx.3s(Optical Wide~Tele)
Angle of View:49-2.2 degree(Wide-Tele)
Minimum Working Distance:10~1,000mm(Wide~Tele)
Aperture Range:F1.4-F3.5

Pan & Tilt
Pan Range:360°endless
Pan Speed:Pan Manual Speed: 0.1°~80°/s, Pan Preset Speed: 80°/s
Tilt Range:-15°-90° (Auto Flip )
Tilt Speed:Tilt Manual Speed: 0.1°~80°/s, Tilt Preset Speed: 80°/s
Proportional Zoom:Rotation speed can be adjusted automatically according to zoom multiples
Number of Preset:256
Patrol:8 patrols, up to 32 presets per patrol
Pattern:4 patterns, with the total recording time not less than 10 minutes
Power loss recovery:Support
Park Action:Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan
PTZ Position Display:ON/OFF
Freeze Frame:Support
